Dongfeng Pure-Electric 15cbm Sweeper

Q: What warranty and after-sales support do you provide?

Two-year warranty on the whole vehicle, lifelong genuine spare parts supply at factory price, free technical training for your maintenance team, and video/online support for installation and debugging.

Dongfeng Pure-Electric 15cbm Sweeper for Zero-Emission Streets

Silent, tailpipe-free street cleaning comes from this DONGFENG 4X2 battery-electric sweeper (street sweeper), a 160 kW drivetrain on a 5300 mm wheelbase with 18000 kg gross, 5120 kg rated load and 295/80R22.5 18PR tires. The CATL pack stores 282 kWh at 618.24 V, charges in 2.5 hours on a recommended 120 kW pile and carries 310 km at full load, while a permanent magnet synchronous motor drives the chassis and battery power spins the fan and pumps independently of the road system. Up top, 8 cubic meters of water and 7 cubic meters of dust sit in stainless tanks and bin; dual side brooms plus central suction sweep 2.4 to 3.5 m full width, with a Sanyo motor, GTM high-pressure pump and maintenance-free centrifugal fan behind stainless pipelines. Kerb-flush side jets clean the gutter line, a 15 m high-pressure reel extends reach, and anti-overflow plus low-water alarms guard the tanks. A cab panel runs one-key sweep programs, an indoor monitor tracks reversing and sweeping status, and a tail LED arrow light warns traffic. Hospital zones, night rounds and city streets gain a zero-emission option that no diesel sweeper can match.

WhatsApp your destination port - FOB price within 24 hours, plus the full spec sheet.

Reply within 12 hours · MOQ 1 unit · Build 15–30 days · Tell us your chassis, drive, capacity and color needs — we build to order

Factory-direct price (no trader markup) Supports 100% customization 2-year warranty + lifetime parts Full export docs (B/L, CO, invoice)

New Products

SHACMAN 6x4 35-Ton Heavy Dump Truck for Mining Hauls

HOWO 8-Stall Mobile Toilet Truck for Events & Sites

ISUZU LPG Tanker for Flammable Gas Delivery

FAW 12 meters Aerial work vehicle

SINOTRUK HOWO 4x2 5-Ton Light Dump for Sand & Gravel

SINOTRUK 371HP 6X6 Flatbed Truck with 16-Ton XCMG Crane for

SINOTRUK NX 8X4 Truck Mounted with XCMG SQZ560 Folding Crane

Geely Farizon Electric Refrigerated Truck for Green Cold Cha

IVECO Daily Transfer Ambulance for Hospital Patient Moves

FOTON View G9 Ambulance 5-7 Seats for Clinic Response

JMC Mobile Clinic Van for Community Health Screening

SINOTRUK TX Mobile Accommodation Vehicle for Field Crews & R

FORD Transit Mobile Command Vehicle with Lift LED Screen

IVECO Mobile CT Ambulance for Stroke Response

JMC Mobile Dental Van for School & Community Care

Brand New High Quality Dongfeng Warriors 4x4 Ambulance for O

IVECO 9-Seat Personnel Carrier Ambulance for Crew Moves

ISUZU 4WD Pickup Mobile Drainage Pump for Confined Flooding

IVECO Gas-Rescue Vehicle with SCBA for Confined-Space Teams

FORD T8 Monitor Ambulance Large Cabin for ICU Teams

Dongfeng T3 Bitumen Sprayer Truck for Pavement Preservation

SHACMAN M3000 Synchronous Chip Sealer for Pavement Care

SINOTRUK 6x4 Sync Chip Sealer & Binder Sprayer

SHACMAN M3000 6x4 Chip Sealer with Dual Heater

Product Details

Sweep-suction body with stainless wear plates, dust suppression and large-capacity tanks, sweeping roads, ports and industrial parks in one pass.

General	Vehicle Brand	DONGFENG
	Overall Dimension	9000×2550×3240(mm) mm
	Rated Load Capacity	5120 kg
	Total Mass	18000 kg
Cab	Air Conditioner	Standard
Engine	Fuel Type	Electric
	Power	160KW/217HP
	Displacement	0
Chassis	Drive Type	4X2
	Chassis Brand	DONGFENG
	Wheelbase	5300 mm
Top Structure	Sweep System	Dual side brooms + central suction, full-width sweep 2.4-3.5 m
	Trash Tank	15 m3 debris hopper with stainless wear lining
	Water Tank	Spray-suppression water tank with flush nozzles
	Vacuum Fan	High-flow fan, dust capture with filter shaker
	Dust Control	Wet sweep + filtration keeps exhaust clean at the kerb
	Nozzles	Kerb-flush side jets for gutter line cleaning
	Discharge	Hydraulic hopper lift for tip-out at depot
	Control	Cab panel with one-key sweep program; ground maintenance panel
	Power	Engine PTO main fan; auxiliary diesel for full-sweep duty
	Application	Silent zero- sweeping
	Options	Self-cleaning filter, mist cannon mount, high-pressure washer, GPS route log
	Docs & Warranty	GB announcement; 2-year upfit warranty
	Drivetrain	Pure electric, battery-driven fan and pumps, depot fast charge
	Upper loading volume	8 cubic meters of water, 7 cubic meters of dust
	Battery Brand	CATL
	Battery Power	282KWH
	Battery charging time	2.5h
	Full load endurance	310KM
	Battery pack rated voltage/recommended charging pile power	618.24V/120KW
	Other Configuration	The chassis battery provides power and the permanent magnet synchronous motor drives the vehicle. The speed can be adjusted in real time according to the needs. The power take-off operation is not related to the chassis driving system, and the vehicle user experience is excellent. It has 2 central sweepers, a Sanyo motor, a GTM high-pressure water pump, an Wanye gear pump, a Hyprius hydraulic cylinder, a universal high-pressure curb cleaning, a maintenance-free centrifugal fan, a stainless steel water tank and trash bin, stainless steel high-pressure pipelines, a Schneider control switch, an American sensor, a tail LED arrow light, the trash bin and water tank are equipped with anti-overflow or low water level alarm devices, an indoor monitoring system for reversing and sweeping status, an electronic control system at the tail, a 15m high-pressure washing reel with a maximum cleaning width of 3.5m, and a high-pressure washing width of 21m. The electrical system consists of a chassis vehicle circuit dedicated working device operation control circuit.
