| Body Color | White(Customized) | Fuel Type | Diesel |
|---|---|---|---|
| Engine Model | SINO 371HP | Displacement & Power | 9726ml / 272kW |
| Emission Standard | Euro 2 | Steering Type | Steering Wheel |
| Number of Tires | 10 | Tire Specification | 12.00R20 18PR |
| Wheel Track (Front/Rear) | 2040mm / 1860mm/1860mm | Wheelbase | 4350+1350mm |
| Axle Load (kg) | 6700kg/18000kg (2-axle group) | Number of Axles | 3 |
| Leaf Spring | 9 pieces / 10 pieces | Overall Dimensions | 10000mm × 2500mm × 3200mm |
| Gross Vehicle Weight | 24700kg | Curb Mass | 7980kg |
| Front/Rear Axle | 9/16T | Seating Capacity of Cab | 3 persons |
| Maximum Design Speed | 90km/h | ||
| Upper Structure | |||
| Tank Effective Volume | 21 CBM | ||
| Tank Material | High-quality Q235 carbon steel from WISCO | ||
| Tank Thickness | 5mm | Operating Platform | CL standard large working platform |
| Internal Tank Structure | Built-in anti-wave baffles, baffles full welded with triangular reinforcement supports, double support structure, reinforced tank assembly | ||
| Surface Treatment | Electrophoretic anti-corrosion coating for all superstructure & accessories; color galvanized saddle bolts | ||
| Tank Color | To be confirmed | ||
| Sprinkling Functions | Front flushing, rear sprinkling, side spraying | ||
| Rear Water Cannon | Fire-fighting type water cannon, adjustable modes: heavy rain, moderate rain, drizzle, mist, jet stream; jet stream range ≥30m | ||
| Reserved Port | Reserved duckbill nozzle interface | Rear Platform | Punched rear working platform |
| Water Pump | High-power dedicated sprinkler pump, self-priming & self-discharging | ||
| Standard Accessories | Fire hydrant port, gravity flow valve, hose connector, three-way filter, other standard fittings | ||
