Dongfeng 4X2 Mist Fog Dust Suppression Truck for Dust Control at Yards & Sites

Technical Specifications

Why an Electric Mist Cannon Truck Pays Off

▶ Construction dust, coal stockpiles and port handling release PM10 and PM2.5 that drift far beyond the site fence. A water sprinkler wets the surface, but a mist cannon adds a second layer of control: it breaks water into fine droplets and throws them 30-60 m, catching dust before it rises. This Dongfeng 4X2 combines both duties on one 18 t chassis, so a single driver and vehicle cover road watering, green-belt irrigation and dust suppression.

The cannon pans and tilts by remote control and offers jet, rain and mist patterns. Its 108-nozzle stainless steel ring is fed by a self-priming sprinkler pump, while the fan runs from the battery pack instead of an auxiliary diesel engine. The result is quiet, zero-tailpipe operation for city roads, demolition sites and night shifts where diesel noise or emissions would be restricted.

Size the tank around the duty cycle, not the other way round. A 30-60 m throw covers a wide area, but water use rises with wind and with the mist setting; tell us the shift length, the material being handled and the refill points, and we will calculate tank volume and pump timing. The 4X2 chassis with a 4,500 mm wheelbase stays maneuverable in yards and on urban roads, and the 160 kW electric motor removes the need for a separate dust-control machine.

On-Site Operation

• Work with the wind: park upwind and use the cannon's pan range instead of moving the truck for every pass.
• Inspect the nozzle ring and filters at the start of each shift; a partly blocked ring cuts throw and raises water consumption.
• Use the rear duckfoot spray on haul roads and the elevated cannon on stockpile faces and demolition fronts.
• Drain the plumbing before freezing weather and keep the pump-in/pump-out routine on the shift checklist.

Frequently Asked Questions

What is the maximum dust suppression distance?

The mist cannon throws 30-60 m depending on wind, water pressure and the selected pattern. For site planning, use the lower end of the range and overlap passes.

Is the truck fully electric?

Yes. The 160 kW motor drives the chassis, and the cannon fan runs from the battery pack, so there is no auxiliary diesel engine. Battery capacity and charging options are confirmed for each configuration.

Can it also irrigate greenery and wash roads?

Yes. The same tank and pump feed the front flush nozzles (14 m), side sprinklers and the rear duckfoot spray (28 m), so the truck works as a water sprinkler outside dust-control duty.

Tell us your duty cycle, preferred chassis and destination port for a specification and quotation within 24 hours.
