Municipal route density drives the spec of this SHACMAN 4x2 compactor: 154 kW / 210 hp, six forwards and two reverses, 4700 mm wheelbase, 18000 kg gross and 7870 kg payload on 10.00R20 tires. Its 14 m3 body is a double-arch, fully sealed construction in 5 mm Q345 manganese steel, full-penetration welded without stiffening ribs, with a reinforced floor and filler hopper.
Two-way compression at 1:2 to 1:3 is delivered by a rear hopper with plunger packer and scraper, taking 240 L or 660 L bins on the standard flip lifter, with loading in 25 seconds or less and discharge within 45. A Siemens PLC offers one-button auto or manual programs from left and right ground boxes or the cab-side pendant; imported multi-way and balance valves with hydraulic locks govern the circuits. Rear and side sewage tanks quick-drain behind a full-perimeter seal band, and gearbox PTO power avoids an auxiliary motor.
WhatsApp your destination port - FOB price within 24 hours, plus the full spec sheet.
SHACMAN 6x4 35-Ton Heavy Dump Truck for Mining Hauls
HOWO 8-Stall Mobile Toilet Truck for Events & Sites
ISUZU LPG Tanker for Flammable Gas Delivery
FAW 12 meters Aerial work vehicle
SINOTRUK HOWO 4x2 5-Ton Light Dump for Sand & Gravel
SINOTRUK 371HP 6X6 Flatbed Truck with 16-Ton XCMG Crane for
SINOTRUK NX 8X4 Truck Mounted with XCMG SQZ560 Folding Crane
Geely Farizon Electric Refrigerated Truck for Green Cold Cha
IVECO Daily Transfer Ambulance for Hospital Patient Moves
FOTON View G9 Ambulance 5-7 Seats for Clinic Response
JMC Mobile Clinic Van for Community Health Screening
SINOTRUK TX Mobile Accommodation Vehicle for Field Crews & R
FORD Transit Mobile Command Vehicle with Lift LED Screen
IVECO Mobile CT Ambulance for Stroke Response
JMC Mobile Dental Van for School & Community Care
Brand New High Quality Dongfeng Warriors 4x4 Ambulance for O
IVECO 9-Seat Personnel Carrier Ambulance for Crew Moves
ISUZU 4WD Pickup Mobile Drainage Pump for Confined Flooding
IVECO Gas-Rescue Vehicle with SCBA for Confined-Space Teams
FORD T8 Monitor Ambulance Large Cabin for ICU Teams
Dongfeng T3 Bitumen Sprayer Truck for Pavement Preservation
SHACMAN M3000 Synchronous Chip Sealer for Pavement Care
SINOTRUK 6x4 Sync Chip Sealer & Binder Sprayer
SHACMAN M3000 6x4 Chip Sealer with Dual Heater
Municipal route density drives the spec of this SHACMAN 4x2 compactor: 154 kW / 210 hp , six forwards and two reverses, 4700 mm wheelbase, 18000 kg gross and 7870 kg payload on 10.00R20 tires.
| SHACMAN 14cbm Compactor Refuse Truck for Municipal Fleets | ||
| General | Vehicle Brand | SHACMAN |
| Overall Dimension | 8800x2550x3300 mm | |
| Rated Load Capacity | 7870 kg | |
| Total Mass | 18,000 kg | |
| Cab | Air Conditioner | Standard |
| Engine | Fuel Type | Diesel |
| Power | 154kw/210hp | |
| Chassis | Drive Type | 4X2 |
| Chassis Brand | SHACMAN | |
| Transmission | 6 Forward,2 Reverse | |
| Wheelbase | 4700 mm | |
| Top Structure | Body Volume | 14 m3 double-arch fully sealed body |
| Compression | Two-way compression, typical ratio 1:2 to 1:3 | |
| Body Material | 5 mm Q345 manganese steel, full-penetration welded arc body without stiffening ribs; reinforced floor and filler hopper | |
| Loading Mechanism | Rear hopper with plunger packer + scraper; 240/660 L bin flip lifter standard | |
| Cycle Times | Loading | |
| Control | Siemens PLC one-button auto/manual; left + right ground control boxes plus cab-side pendant | |
| Hydraulics | Imported multi-way and balance valves; cylinders with hydraulic locks; filler-lift interlock | |
| Sewage & Sealing | Rear + side sewage tanks with quick drain; full-perimeter rubber seal band — zero leakage on route | |
| Power | Gearbox PTO from engine — no auxiliary motor; night work light and travel alarm standard | |
| Options | Reversing camera, large ground bucket, arm-compression combo, stainless liner, 1100 L lifter | |
| Docs & Warranty | GB announcement + purchase-tax exemption; 2-year upfit warranty, lifetime spare parts | |
| Tank Capacity | 14 m³ | |
Factory Direct CLW Chengli, Suizhou — ISO 9001 & CCC certified | MOQ 1 Unit Mixed batch and stock chassis available | Export Ready SEA / Ro-Ro / container + full documents | Lifetime Support Genuine parts and remote commissioning |
