Between a DONGFENG 6X4 tractor and the terminal gate, this 40ft container flatbed semi-trailer is built around three FUWA or BPW 13 t axles with drum or disc brakes, riding mechanical parabolic suspension or an optional air bag setup. Running gear takes 11.00-20 or 295-315 tires per route specification, with ABS standard and an EBS upgrade available for demanding corridors.
At the nose, a JOST 2 inch bolt-on kingpin mates to the tractor and a JOST 28 ton landing gear supports the uncoupled trailer. The 2 mm checkered steel deck can alternatively be laid with a wooden floor, and optional end ramps let self-propelled cargo drive aboard for yard moves. An ISO/CSC plate and a complete export build sheet document the structure for international operation.
Port shuttling, container transfer and project freight under long-wheelbase 6X4 traction are the design targets, whether the load is a tank container, a flat rack or boxed cargo moving between terminal and construction site.
WhatsApp your destination port - FOB price within 24 hours, plus the full spec sheet.
SHACMAN L3000 4x2 210HP Skip Loader Garbage Truck 10m3
SHACMAN F3000 8x4 Aircraft Refueling Truck 14,000 L JET A-1
FOTON Aumark 4.5-Ton Light Wrecker for Mall & Port Patrol
Dongfeng 4X2 10.62 cbm Water Sprinkler Truck for Road Washin
ISUZU 4X2 10 cbm Compactor Garbage Truck for Municipal Waste
HOWO 8x4 400HP with 35-Ton Crane for Heavy Project Lifts
IVECO Daily ICU Ambulance for Critical Care Transport
FAW Jiefang 4X2 12 cbm Road Sweeper Truck for City Arterial
ISUZU 6X2 3 cbm Foam Fire Truck for Industrial Fire Response
SINOTRUK 4x2 Light Dump with Electric Tarp for City Muck
Dongfeng 4X2 4 cbm Sewage Suction Truck for Municipal Sewer
ISUZU 4X2 12 cbm Refrigerated Box Truck for Cold-Chain Deliv
ISUZU 32 m Aerial Platform Truck for Utility Maintenance
HOWO 6x4 Aircraft Refueling Truck 12,000 L JET A-1 Bowser wi
Dongfeng Tianlong 8x4 Aircraft Refueling Truck 30,000 L JET
Dongfeng 8X4 22000L Fuel Tanker Truck
20 CBM Water Sprinkler Truck for Sale – SHACMAN F3000 6x4 30
16 CBM Compactor Garbage Truck for Sale – Dongfeng 4x2 Rear
14 Ton Crane Truck for Sale – HOWO 8x4 with ZOOMLION 5-Secti
12 Ton Crane Truck for Sale – HOWO T5G 6x4 with KAIMEI Boom
ISUZU GIGA 6x4 10 Ton XCMG Truck Mounted Crane for Sale with
ISUZU GIGA 4x2 12 CBM Water Sprinkler Truck for Sale – 12,00
ISUZU ELF 4x2 32m Manlift Bucket Truck for Sale with 200 kg
25 Ton Dump Truck for Sale – SHACMAN F3000 6x4 380 HP with 5
Heavy-duty trailer: high-strength steel frame, FUWA/BPW axles and hot-dip galvanized finish, export-ready.
| 40ft 3-Axle Container Flatbed Semi-Trailer for Ports | ||
| General | Overall Dimension | 13000x2500x1650 mm |
| Total Mass | 40000 kg | |
| Top Structure | Deck | 2 mm checkered steel / wooden floor optional |
| King Pin | JOST 2 inch bolt-on | |
| Landing Gear | JOST 28 ton | |
| Axles | FUWA/BPW 13 t x3, drum or disc | |
| Suspension | Mechanical parabolic or air bag option | |
| Tires | 11.00-20 / 295-315 per route spec | |
| Brakes | EBS option; ABS standard | |
| Ramps | Optional end ramps for self-loading | |
| Application | Port, container and project freight | |
| Docs | ISO/CSC plate; export build sheet | |
Key Upfit Features
| Factory Direct CLW Chengli, Suizhou — ISO 9001 & CCC certified | MOQ 1 Unit Mixed batch and stock chassis available | Export Ready SEA / Ro-Ro / container + full documents | Lifetime Support Genuine parts and remote commissioning |
